AL-KO Genuine Trailer Bolt On Ring Coupling Zinc 6000kg

The Product:

• When used in a commercial or defence department application, often a 75 mm ring type towing eye is requested.
• This style of coupling is similar in function to ball type couplings (fixed and over ride ) but instead of the connection to the tow vehicle being a standard 50 mm ball, the connection is a 75 mm inside diameter ring and this attaches to a “pintle hook” fitted to the tow vehicle.
• These types of couplings are primarily used in applications where the tow vehicle is a heavy commercial truck. As the Australian Standard AS 4177 states the 50mm towball to have a maximum capacity of 3500 kg AT M (total loaded mass), ring couplings are used when higher loads are involved
• ADR Compliant and made to Australian standards!

Specifications:

• AL-KO Part Number: 614309
• Rating: 6000kg
• Ring Size: 75mm (3")
• Mounting Hole (LxW): 182mm x 52mm
• Mounting Hole Diameter: 16.8mm
• Surface Finish: Zinc Plated
• Ring Centre To First Mounting Hole (Nominal): 116mm

Order Includes:

• 1 x AL-KO 6000kg Fixed Zinc Plated Ring Coupling

If you have any queries please contact us via eBay message

We thank you for considering Autocrave Australia and look forward to dealing with you soon.
